This product is custom-optimized at the circuit level for pet monitoring scenarios. The core circuit modules are designed as follows, with each feature directly addressing the most common pain points reported by users on e-commerce platforms:

1. Main Control Chip & AI Computing Circuit Design

Core Design:Adopts a low-power AIoT main control chip customized for smart home vision applications, equipped with a dual-core ARM Cortex-A53 processor + NPU neural processing unit with over 1 TOPS computing power. It integrates a hardware ISP image processor and H.265+/H.264 dual-format video encoder/decoder.The PCB uses a 4-layer immersion gold design. Key signal traces of the main control unit feature 50Ω impedance matching; differential pair length mismatch is controlled within 5mil, and full-loop ground shielding reduces signal crosstalk.

Pain Points Solved:Eliminates common industry issues such as high false AI recognition rates, video encoding lag, overheating crashes during 7×24 operation, and frequent disconnections caused by insufficient computing power of general main control chips. It supports on-device AI inference without cloud computing, greatly reducing latency and data leakage risks.

2. Image Sensor & ISP Image Processing Circuit Design

Core Design:Built with a 1/2.8-inch starlight CMOS image sensor (2MP/4MP optional), paired with an F1.6 large-aperture 8-layer optical glass distortion-free lens. Supports hardware-level 120dB WDR, 2D/3D digital noise reduction, and 3A algorithms (AE, AWB, AF).The sensor and ISP communicate via a high-speed MIPI-CSI2 differential interface, with ISP parameters tuned specifically for pet fur details, low-light environments, and backlit balcony scenes.

Pain Points Solved:Fixes severe wide-angle distortion, dark faces in backlight, blurry night vision, lost pet fur details, and motion blur. Delivers 150° ultra-wide-angle monitoring with clear imaging in all scenarios.

3. Night Vision & IR-CUT Dual-Filter Switching Circuit Design

Core Design:Uses 940nm non-red-flush infrared LEDs (invisible to cats and dogs, whose visible spectrum is 380–780nm). Equipped with a closed-loop constant-current driver that adjusts brightness linearly via photoresistor AD sampling.The IR-CUT dual-filter electromagnetic switching circuit is optimized for anti-shake and anti-jamming, with a service life of over 100,000 operations. It automatically switches between IR-cut filter (daytime) and full-spectrum filter (nighttime).

Pain Points Solved:Eliminates harsh red glow from traditional 850nm IR LEDs that frighten pets. Also corrects color cast, overexposure, insufficient brightness, and failure to image in total darkness, providing invisible and non-intrusive night vision.

4. RF & Wireless Communication Circuit Design

Core Design:Adopts Wi-Fi 6 (802.11ax) 2.4G/5G dual-band + Bluetooth 5.3 dual-mode wireless solution. Equipped with an independent dual-band PCB antenna + IPEX external antenna base. RF traces use 50Ω impedance matching with π-type debugging circuits and full metal shielding to reduce EMI from the main control and power circuits.Supports hardware-level H.265+ intelligent bitrate control: lower bitrate for static scenes, higher bitrate for moving pets.

Pain Points Solved:Improves wall penetration and anti-interference performance by 80%, reduces packet loss rate, and ensures stable remote viewing with latency below 200ms even on mobile networks.

5. Audio Codec & Echo Cancellation Circuit Design

Core Design:Integrates high-fidelity MEMS microphones (SNR ≥94dB) and a dedicated audio codec chip with hardware AEC, ANC, and AGC algorithms.Audio I/O circuits are electrically isolated; microphone differential traces are routed away from power and RF lines to avoid noise. The speaker uses a Class D amplifier with distortion <1%, optimized for pet sounds.

Pain Points Solved:Eliminates noise, echo, howling, and distorted audio. Captures subtle pet sounds within 3 meters and enables full-duplex two-way calls without startling pets.

6. Power Management & Low-Power Circuit Design

Core Design:Dual versions: plug-in and battery-powered.

• Plug-in: Wide-voltage Type-C 5V/2A input, high-efficiency synchronous step-down DC-DC converter (>95% efficiency), no-load power <50mW, with over-voltage, over-current, over-temperature, and short-circuit hardware protection.

• Battery: Multi-level sleep-wake architecture with PIR motion detection; standby current <100uA, full lithium battery protection (over-charge, over-discharge, over-current).

Pain Points Solved:Plug-in version runs 7×24 without overheating. Battery version lasts up to 6 months on a single charge.

7. Storage & Security Encryption Circuit Design

Core Design:Built-in dedicated hardware security encryption chip supporting AES-256 symmetric encryption for full-link video protection. High-speed SDIO 3.0 interface supports up to 256GB TF card loop recording. ESD and power-off protection prevent data corruption.

Pain Points Solved:Prevents privacy leaks and data theft at the circuit level. Local storage is free with no mandatory subscription fees.

8. EMC & Heat Dissipation Reliability Design

Core Design:4-layer PCB with complete ground and power layers, common-mode inductors, and ESD protection, complying with GB/T 17626 EMC standards.High-thermal-conductivity silicone pads and metal shields are applied to heat-generating chips for efficient natural convection cooling.

Pain Points Solved:Stable operation even in high summer temperatures; body temperature controlled within 50°C during 7×24 use, no crashes or disconnections.

II. Core Technical Specifications

III. Core Selling Points

1. 940nm Invisible Night Vision – No Glare, No Stress

No red light, no irritation to pets’ eyes. Clear imaging even in total darkness without disturbing rest.

2. Dual‑Band Wi‑Fi 6 – Stable Remote Viewing, No Lag

Stronger wall penetration, 80% better anti-interference, <200ms latency. Never disconnect when you need it most.

3. On-Device AI Pet Recognition – Accurate Alerts

90% fewer false alarms. Detects pet movement, barking, and abnormal behavior; auto-tracking for full coverage.

4. Full-Duplex Two-Way Audio – Clear & Gentle Talk

Noise cancellation and echo elimination. Talk to your pet naturally without scaring them.

5. Hardware-Level AES‑256 Encryption – Privacy Protected

Full-link encryption prevents hacking. Local TF card storage is free with no hidden fees.

6. Dual Power Options – Flexible Installation

Plug-in for 7×24 monitoring; battery-powered for wire-free placement, up to 6 months per charge.
